Kinefinity MAVO Edge 6K cinema camera body
NewNew
A compact full frame 6K cinema camera with a built in motorised e-ND, internal Apple ProRes recording and dual SSD slots. Body only, new.
- 6K full frame 3:2 sensor, 6016 x 3984 open gate, 36 x 24 mm
- Dual base ISO 800 and 5120, more than 14 stops of dynamic range
- Built in motorised e-ND from 0.6 to 2.4 (2 to 8 stops)
- Apple ProRes 4444 XQ, 4444 and 422 HQ recording, plus CinemaDNG RAW
- 2 KineMAG Nano SSD slots (NVMe M.2), media sold separately
- KineMOUNT with PL, LPL, EF and E adapters available (sold separately)
For EU customers only. Price includes VAT. Lead time on request: we confirm it after you order. Quantity 1 per order. You pay in EUR on the secure Stripe checkout page.
- For EU customers only. Price includes VAT
- Lead time on request: we confirm it after you order
- EU consumers: 14 day right of withdrawal, return shipping paid by you. Details
- 2 year legal guarantee in the EU, plus our shop's own warranty
Description
The Kinefinity MAVO Edge 6K is a compact full frame cinema camera. It pairs a 6K 3:2 full frame CMOS sensor with a built in motorised e-ND, internal Apple ProRes recording and dual SSD media slots, all in a 1.6 kg aircraft aluminium body in Kinefinity's official dark grey finish with a red mount ring. Dual base ISO of 800 and 5120 with more than 14 stops of dynamic range, up to 75 fps in full frame 6K Wide and up to 150 fps in S35 4K Wide make it suited to narrative, commercial and documentary work. This listing is for the camera body only: lens, mount adapters, monitor, viewfinder, media, batteries and rigging are not included. Specifications are from Kinefinity's official MAVO Edge 6K page.
Specifications
| Sensor | 6K full frame 3:2 CMOS, 6016 x 3984 open gate, 36 x 24 mm |
|---|---|
| Frame rates | Up to 75 fps FF 6K Wide, up to 150 fps S35 4K Wide |
| ISO | Dual base 800 (500 to 2560) and 5120 (3200 to 20480) |
| Dynamic range | More than 14 stops |
| ND | Motorised e-ND 0.6 to 2.4 (2 to 8 stops) |
| Recording | Apple ProRes 4444 XQ / 4444 (12 bit), 422 HQ / 422 / LT (10 bit), CinemaDNG RAW (12 bit) |
| Media | 2 x KineMAG Nano SSD (NVMe M.2) |
| Lens mount | KineMOUNT (PL, LPL, Active EF and passive E adapters sold separately) |
| Outputs | 2 x 3G/1.5G SDI, 2 x Kinefinity video ports |
| Audio | 4 channel 24 bit / 48 kHz, 2 x XLR with 48V phantom, 3.5 mm mic in, headphone out |
| Connectivity | Gigabit Ethernet, WiFi 5, timecode in/out, USB-C |
| Power | Integrated V-mount plate (V-mount or BP-U compatible), DC 11 to 26 V, about 29 W |
| Body | Aircraft aluminium, dark grey finish with red mount ring |
| Weight | 1.6 kg |
| Dimensions | 106 x 124 x 109 mm (W x H x L), without protrusions |
| Operating temperature | 0 to 40 °C |
What's in the box
- Kinefinity MAVO Edge 6K camera body
